On-line tension sensors for continuous digital tension monitoring


On-line tension sensors are used for continuous digital tension monitoring in various industrial and laboratory applications such as textile, yarn and wire industry.

We offer tension load cells for miscellaneous measuring tasks. Due to different sensor and roller designs and large measuring ranges the sensors can be aligned for diverse applications.



TS1 Tension Sensor

TS1
  • 10 Tension Ranges from from 0 - 50 cN up to 0 - 50 daN
  • Wire and textile industry
  • Threads and fibres up to 50.000 tex and wires up to approx. Ø 2 mm
  • Versatile Tension sensor
More information

TE General Purpose Tension Sensor

TE
  • General Purpose Tension Sensor
  • 10 Tension Ranges from 0-50 g up to 0-50.0 Kg
More information

TSF - Optic Fiber Tension Sensor

TF
  • Optic Fiber Tension Sensor
  • 6 Tension Ranges from 0–100 g up to 0–5.00 Kg
  • Large 70 mm aluminum rollers minimize bending of material which might damage or break the fragile filament.
More information

TE-22 Low Inertia Tension Sensor For Fragile Filaments

TE-22
  • Low Inertia Tension Sensor For Fragile Filaments
  • 5 Tension Ranges from 0-50 g up to 0-1000 g
  • Lightweight 32mm diameter rollers minimize the deflection of the material path for fragile filaments or very low tension applications.
More information

TE-24 Heavy-Duty Tension Sensor

TE-24
  • Heavy Duty Tension Sensor
  • 6 Tension Ranges 0-1000 g up to 0-20.0 Kg
  • Heavy-duty, hardened steel rollers makes this model especially suitable for tire cord, wires and similar filaments to high-impact loading.
More information

TSB1 Tape & Band Tension Sensor

TSB1
  • 8 Tension ranges from 0 - 100 cN up to 0 - 20 daN
  • Ribbons, filaments, carbon strands, foils and similar flat materials
  • Max. width of material 30 mm
  • Cylindrical tape rollers are mounted on one side
More information

TSB2 Tension Sensor

TSB2
  • Tension Meter
More information

TSH Tension Sensor TSH

TSH
  • 6 Tension ranges from 0 - 1000 cN up to 0 - 50.00 daN
  • For flexible material as wires, thin ropes and cables up to 15 mm Ø
More information

TSP Tension Sensor TSP

TSP
  • TSP Tension Sensor with non-rotating ceramic pins
  • 5 Tension ranges from 0 - 50 cN up to 0 - 1000 cN
  • Textiel industrie, texturisering, spinning
  • for fibres up to 1000 tex
  • with non-rotating ceramic pins for high line speed of max. 6000 m/min
More information

TE-RFS Multi-Configuration Tension Sensor

TE-RFS
  • Multi-Configuration Tension Sensor
  • Several ranges up to 500 Kg (5000 N / 1100 lbs)
More information
