ESH High Capacity Mechanical Force Gauge


The ESH series mechanical force gauge is designed for high capacity measurements from 200 lbs up to 500 lbs (300 kg). The rugged metal housing and heavy duty springs will withstand the harsh rugged environment of a manufacturing plant, yet the highly accurate, matched springs will ensure reliable results and retain their accuracy over long periods. The tare ring allows you to zero the gauge and compensate for measuring attachments and changes in measuring position. The real time/peak hold selector switch enables you to observe transients or capture peaks. ESH force gauges are available in pounds, kilograms and Newtons. No batteries are needed and the unit is intrinsically safe in hazardous environments.

The ESH mechanical force gauge has an accuracy of 0.5 % of the full scale. A higher accuracy of 0.3% is available on request. Please contact us for more information.


Features
  • Capacities up to 500 lbs / 300 kg (push and pull)
  • Heavy duty metal construction
  • Real time and peak mode
  • Easy to read dial
  • Full set of acessories and carrying case included
  • No batteries needed
  • ISO/IEC 17025 Long-form Certificate & Test Data is optionally available
  • Simple , vitually maintance free
  • Zero Tare Ring to zero the gauge in each position
  • 2 Year Warranty

Tension Ranges
ModelRanges
ESH-200 200 lb (2 lb)
ESH-300 300 lb (2.5 lb)
ESH-400 400 lb (4 lb)
ESH-500 500 lb (5 lb)
ESH-100 kg 100 kg (1 kg)
ESH-200 kg 200 kg (2 kg)
ESH-300 kg 300 kg (2.5 kg)
ESH-1000 N 1000 N (10 N)
ESH-2000 N 2000 N (20 N)
ESH-3000 N 3000 N (25 N)
M10p1.5 Threaded measuring shaft (top & bottom)

Displacement at full scale capacity is 10mm


Complete Kit
Sold in kit form complete with force gauge, hard plastic carrying case, handles, measuring attachments (hook and flat head), and extension shaft. Four installation bolts are also included for mounting the gauge to a test stand or other permanent location.

Standard Attachments



B-Series (steel, thread M10) attachments are supplied for models 1000 N and more
(1) B-1 Small hook
(2) B-2 Flat tip
(3) B-3 Conical tip
(4) B-4 Chisel tip
(5) B-5 Notched tip
(6) B-6 Extension shaft
(7) B-7 Handles
(8) B-8 Mounting screws


Specifications
Displacement:10 mm
Accuracy:± 0.5% Full Scale (0.3% available on request)
Weight, net (gross):approx. 3100 g (4000 g)
Warranty2 Years

Dimensions
Dimensions ESH


Related Products

Cic-Force Calibration Force Gauge


  • Short turnaround
  • Exclusively in accordance with Deutscher Kalibrierdienst (DKD) working standards, class F1; calibration-no: 19026 - 07
  • Possibility to adjust and repair

More details

Cic-Force Calibration Force Gauge

Buy Now
Products

Product name
Price
Quantity
ESH-200 - ESH Force Gauge
€ 1.146,00
ESH-300 - ESH Force Gauge
€ 1.146,00
ESH-400 - ESH Force Gauge
€ 1.283,00
ESH-500 - ESH Force Gauge
€ 1.283,00
ESH-100 kg - ESH Force Gauge
€ 1.146,00
ESH-200 kg - ESH Force Gauge
€ 1.283,00
ESH-300 kg - ESH Force Gauge
€ 1.283,00
ESH-1000 N - ESH Force Gauge
€ 1.146,00
ESH-2000 N - ESH Force Gauge
€ 1.283,00
ESH-3000 N - ESH Force Gauge
€ 1.283,00

Accessories

Product name
Price
Quantity
ISO-17025 - ISO/IEC 17025 Long-form Certificate & Test Data
€ 176,00
All mentioned prices are excluding VAT & excluding shipment costs.
Availability: Available , preorder 1-2 weeks , special order, request
