Meter Counters




M300 IVO Mechanical Meter Counter With Key Reset

M300 IVO Mechanical Meter Counter With Key Reset
  • Meter counter with key reset
  • Speed
    With wheel of 20 cm: 100m/min
    Without measuring wheel: max 300 m/min.
  • Drive shaft Projecting on both sides, Ø 4 mm
  • Measuring range
    99 999.9 m (decimal in red)

M310 IVO Mechanical Meter Counter

M310 IVO Mechanical Meter Counter
  • Meter counter
  • Speed
    With wheel of 20 cm: 200m/min
    Without measuring wheel: max 300 m/min.
  • Drive shaft Projecting on both sides, Ø 4 mm
  • Measuring range 9 999.9 m (decimal in red)

M310a IVO Mechanical Meter Counter

M310a IVO Mechanical Meter Counter
  • Meter counter
  • Speed
    Max. 60.00 m/min.
  • Drive shaft Projecting on both sides, Ø 4 mm
  • Measuring range
    999.99 m (decimal in red)

M400 IVO Mechanical Meter Counter with Key Reset

M400 IVO Mechanical Meter Counter with Key Reset
  • Meter counter with key reset
  • Speed
    With wheel of 50 cm: 100.0 m/min or max 1000 digits/min.
  • Drive shaft Projecting on both sides, Ø 7 mm
  • Measuring range
    999 999.9 m (decimal in red)

M410 IVO Mechanical Meter Counter

M410 IVO Mechanical Meter Counter
  • Meter counter
  • Speed
    With wheel of 50 cm: 200m/min
    Without measuring wheel: max 3000 digits/min.
  • Drive shaft Projecting on both sides, dia. 7 mm
  • Measuring range 9 999.9 m (decimal in red)

M410a IVO Mechanical Meter Counter

M410a IVO Mechanical Meter Counter
  • Meter counter
  • Speed
    Max. 200.00 m/min. with measuring wheel
  • Drive shaft Projecting on both sides, Ø 7 mm
  • Measuring range
    9999.95 m

M411 IVO Mechanical Meter Counter

M411 IVO Mechanical Meter Counter
  • Meter counter
  • Speed Max. 1000 rev./min.
  • Drive shaft In the middle, projecting downwards, dia. 7 mm
  • Measuring range 9 999.9 m (decimal in red)

ME102 Mechanical Preselection Meter Counter

ME102 Mechanical Preselection Meter Counter
  • Preselection Meter Counter Counts from preset value to zero and triggers a changeover contact
  • Speed
    When 5 rev.=10 dig: 1000 U/min or 200.0 m/min
    When 5 rev.= 1 dig: 10000 U/min or 2000 m/min
    When 1 rev.= 1 dig: 6000 U/min or 6000 m/min
  • Drive shaft Projecting on both sides, Ø 4 mm
  • Measuring range
    Max. 9999m
