MS-2700EX Intrinsically-Safe LED Stroboscope
As of October 2014 the MS-2700EX is no longer available. There is no replacement / alternative model currently available.
The Movistrob MS-2700EX is digital LED hand-held stroboscope specifically-designed for use in the hazardous areas. As with all other stroboscopes it is commonly used to observe, analyze & measure the speed of targets/objects that are in rotational or reciprocating motion. When the flash rate of the LEDs matches the speed of the target, the target will look like it is "frozen" and stationary. If the user adjust the flash rate in either direction it is possible to put the target in "slow motion" allowing you to observe it motion.
It is housed in a extruded aluminum housing with a rating of IP65 designed for use in the toughest applications. It is powered with a 9VDC battery and incorporate 20 LEDs for flash rates up to 20,100 (350 Hz). Best results are likely in low ambient lighting conditions as the brightness is limited and should not be compared to a Xenon Strobe.
The Movistrob MS-2700EX is Intrinsically-Safe and has been certified to European Standards for use in ex-proof areas classified as zone I and 21 according to norm 1999/92/EG (ATEX 137).
The Movistrob MS-2700EX is digital LED hand-held stroboscope specifically-designed for use in the hazardous areas. As with all other stroboscopes it is commonly used to observe, analyze & measure the speed of targets/objects that are in rotational or reciprocating motion. When the flash rate of the LEDs matches the speed of the target, the target will look like it is "frozen" and stationary. If the user adjust the flash rate in either direction it is possible to put the target in "slow motion" allowing you to observe it motion.
It is housed in a extruded aluminum housing with a rating of IP65 designed for use in the toughest applications. It is powered with a 9VDC battery and incorporate 20 LEDs for flash rates up to 20,100 (350 Hz). Best results are likely in low ambient lighting conditions as the brightness is limited and should not be compared to a Xenon Strobe.
The Movistrob MS-2700EX is Intrinsically-Safe and has been certified to European Standards for use in ex-proof areas classified as zone I and 21 according to norm 1999/92/EG (ATEX 137).
Features
- Certified for zone 1 and 21 per European norm 1999/92/EG (ATEX 137)
- Broad field of application up to 20,100 FPM (350 Hz)
- Robust aluminum housing
- Easily change between FPM/RPM and frequency (Hz) units with a touch of a key
- Powered with 9V DC battery
- Lightweight and portable
Related Products
Cic-Strobe Stroboscope Calibration
- Easy planning of calibration
- Short turnaround
- Exclusively using a standard which is traceable to British national standards and International standards ISO/IEC 17025
More details
Specifications
| Frequency range | 60 - 20,100 RPM (FPM/RPM) or 1 - 335Hz |
| Flash duration | 45 - 185µs |
| Light Source | 20 white light LEDs |
| Trigger action | Adjustable via keypad with cursor function, standby (after 2minutes) with data-hold function, automatic switch-off with storage function of the last set value |
| Display | via LC display, selectable in Hz or RPM |
| Accuracy | < ± 0.1% of set value |
| Memory | last value |
| Flash power control / range switching | automatic |
| Power supply | 9V DC battery (block-6LR1) |
| Power consumption | 70mA / Standby 25mA |
| Housing | Aluminium / IP 65 |
| Operating Temperature | -4°F to +122°F (-20°C to +50°C) |
| Weight | ca. 0.400 kg (incl. battery) |
| Dimensions | 178 x 84 x 35 mm / L x W x H |
