X Series High Performance Durometer


The X-Series Asker Hardness testers are portable, easy to use, make non-destructive measurements and can be equiped (optional) with peak indicators. The Asker High Performance series has an accuracy of ±.75 point and is available in Type F for soft materials like sponge rubber and urethane foam.

Common Hardness scales:

  • Model X-A Shore A Hardness - Normal Rubber
  • Model X-D Shore D Hardness - Hard Rubber and plastics
  • Model X-C Asker C Hardness - Soft rubber and sponge
  • Model X-F Asker F Hardness - Urethane foam, sponge and polystyrene foam


Special Hardness Scales:

  • Asker JA Normal rubber & softer plastics
  • Asker B semi rigid rubber & plastics
  • Asker C2 Soft rubber & sponge Asker
  • Asker CS Polystyrene foam
  • Asker E Soft & cellular rubber

Supplied with 3 point NIST traceable calibration cert.

Asker models are available in ASTM D 2240 durometer Types: Shore A Hardness, Shore D Hardness and Asker C Hardness durometer scales.

Conforms to:
JIS K 6253, JIS K 7215, ASTM D 2240, ISO 7619, ISO 868, DIN 53505

All X models are supplied with a NIST traceable calibration certificate.



Operation

As the hardness tester is pressed against the sample, the material resistance force and indentor spring load balance. The depth of the indentor is measured, which provides a measure of the material's hardness. Values are based upon a 100 point scale (accuracy ±.75 point). However, as time elapses the indicator will "creep" back so that a reading taken a few seconds after the tester makes contact with the sample will be less than the peak reading. The optional peak indicator helps to more closely monitor the difference between peak and "creep" in hardness tests.



Specifications

Indication Range:
262 degree dial scale
Minimum indication:
1 point (Accuracy : ± 1 point)
Pressure foot Dimensions:
44 ×18 mm rectangular
Outer Dimensions;
Approx. Width 57 × Depth 30 × Height 76 mm
Mounting Thread:
M6 P1
Weight:
200 grams

Related Products

Cic-Duro Durometer Calibration


  • Easy planning of calibration
  • Short turnaround
  • Exclusively NIST-certified testing equipment
  • Possibility to adjust and repair

More details


Buy Now

Products


Product name
Price
Quantity
X-A - Shore A Hardness - Normal rubber
€ 752,00

X-D - Shore D Hardness - Hard rubber and plastics
€ 786,00

X-C - Asker C Hardness - Soft rubber and sponge
€ 752,00

X-F - Asker F Hardness - Urethane foam, sponge
€ 1.012,00

X-CS - Asker CS Durometer
€ 1.012,00

X-C2 - Asker C2 Hardness - Soft rubber and sponge
€ 1.012,00

All mentioned prices are excluding VAT & excluding shipment costs.
Availability: Available , preorder 1-2 weeks , special order, request
